High speed dispersing kettle
High speed dispersing kettle
Top-mounted execution
Closed system
Height-adjustable toothed disc
Built into steel platform or ceiling
Ideal for automation
Drive by modern frequency converter technology
Batch sitzes of 300 - 10000 kgs
Driving powers of 22 to 312 kW
Suitable and developed for the use in a highly-concentrated initial dispersion quantity (mill charge)
Options
ATEX according to protecttive system Ex II 2 G c IIB T3
mixing container
Double dispersing discs
Vacuum execution
Cleaning nozzles for medium or low pressure
Mixing container in stainless steel execution
Weighing technology/Load cells
Cooling/Heating of the mixing container with double casing or half-pipe coil jackets
Temperature measurement and control
Recipe controlled semi and fully automatic PLC control
Applications
Paints, coatings, plasters
Printing inks
Pigment pastes
Adhesives
Fillers
Sealants
PVC-pastes / floor coverings
Casting compounds
Composite materials
Cosmetic products
Technical specs
|
Type |
Diameter |
Height of kettle |
Dispersing kettle |
Paint mixing kettle |
|||
|
Dispersing |
Paint mixing |
Power |
Speed |
Power |
Speed |
||
|
500L |
800 |
1000 |
1060 |
11.0 |
0～1450 |
1.1 |
112 |
|
1000L |
1000 |
1250 |
1400 |
15.0 |
0～1450 |
2.2 |
112 |
|
2000L |
1400 |
1540 |
1575 |
30.0 |
0～1450 |
4.0 |
112 |
|
3000L |
1500 |
1880 |
1750 |
37.0 |
0～1450 |
5.5 |
88 |
|
4000L |
1600 |
2180 |
2125 |
45.0 |
0～1450 |
7.5 |
88 |
|
5000L |
1800 |
2235 |
2125 |
55.0 |
0～1450 |
11.0 |
88 |
|
6000L |
1900 |
2360 |
2475 |
75.0 |
0～1450 |
11.0 |
88 |
|
8000L |
2000 |
2720 |
2725 |
90.0 |
0～1000 |
15.0 |
88 |
|
10000L |
2200 |
2820 |
3050 |
110.0 |
0～1000 |
18.5 |
65 |
